Karl Mayer Direct Warper & Rotal Sizing Machine

Item#005725

a) 01 Karl Mayer Direct Warper – ZM – SP 1700/1000

year 1997, working width 170 cm,

max. beam flange diam. 1.016 mm

with

01 Karl Mayer warping creel, H-type, 630 creeling positions

disc brakes, electr. stop motion,

pitch 30 cm – adjustable

abt. 60-70 fractional beams (for direct warper and sizing)

b) 01 Karl Mayer Rotal Sizing machine,  type ELC-O-TENS

year 2000, with Pleva humidity and tension control,

warp beam creel

for max. 16 warp beams

nom. working width 170 cm

max. beam flange Ø 1.016 mm

pneum. Brakes

1 sizing double trough

nom. working width 170 cm

pre-wetting

double dip and squeeze roller pairs

Cylinder Dryer

10 drying cylinder Ø 800 mm

partitioning field  abt. 4,5 mtrs.

Waxing device

Beaming machine / headstock

max. nom. working width 240 cm

max. beam flange Ø 1100 mm

speed up to 140 m/min

beam pressure device

Size kitchen

turbo cooker

storage tank
